Supported CPU | Supports Intel 11th Gen Core i9, i7, i5, i3 & Pentium Processors Supports Intel 10th Gen Core i9, i7, i5, i3 & Pentium Processors Supports Intel 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 Intel® Turbo Boost Max Technology 3.0 **Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
Chipset | Intel B460 |
BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
Form Factor | mATX Form Factor 9.6 inch x 9.2 inch ( 24.4 cm x 23.4 cm ) |
Audio | Realtek® ALC887 7.1-Channel High Definition Audio CODEC * - Supports: Jack-detection, up to 24-Bit/192kHz playback Audio Feature : - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors * Choose the chassis with an HD audio module in the front panel to support 8-channel audio output. |
Chipset Brand | Intel |
Chipset | B460 |
Supported Sockets | LGA1200 |
Graphics | Integrated Graphics Processor- Intel® UHD Graphics support 1 x DisplayPort 1.4 1 x HDMI 1.4b 1 x DVI-D **Graphics specifications may vary between CPU types. **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. |
Slots | 4 x DIMM |
Supported Memory | DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Supports Intel® Extreme Memory Profile (XMP) OptiMem |
Maximum Memory | 128GB |
Memory MHz | Up to 2933MHz |
Storage Interface | 6 x SATA 6Gb/s ports |
SSD Expansion Slot | 2 x M.2 SSD Expansion Slot |
PCI | Intel® 10th Gen Processors -1 x PCIe 3.0/2.0 x16 (x16 mode) Intel® B460 Chipset -2 x PCIe 3.0/2.0 x1 |
M.2 Socket | 1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) 1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) Support Raid 0, 1, 5, 10 Intel® Rapid Storage Technology supports Intel® Optane™ Memory Ready |
HDMI | 1 x HDMI |
USB (s) | 4 x USB 3.2 Gen 1 Type-A 2 x USB 2.0 |
LAN Port (s) | Realtek® RTL8111H, 1 x Gigabit LAN Controller(s), support LANGuard |
Audio | Realtek® ALC887 7.1-Channel High Definition Audio CODEC * - Supports: Jack-detection, up to 24-Bit/192kHz playback Audio Feature : - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors * *Choose the chassis with an HD audio module in the front panel to support 8-channel audio output. |
Internal I/O Ports | - 1 x CPU Fan connector(s) (1 x 4 -pin) - 1 x CPU OPT Fan connector(s) (1 x 4 -pin) - 2 x Chassis Fan connector(s) (2 x 4 -pin) - 1 x AAFP connector - 2 x Aura RGB Strip Header(s) - 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) - 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) - 2 x M.2 Socket 3 - 1 x LPT header - 6 x SATA 6Gb/s connector(s) - 1 x S/PDIF out header(s) - 1 x 24-pin EATX Power connector(s) - 1 x 8-pin ATX 12V Power connector(s) - 1 x System panel(s) (Chassis intrusion header is inbuilt) - 1 x Clear CMOS jumper(s) - 1 x COM port header |
TPM (Trusted Platform Module ) | - 1 x SPI TPM header |
Display Port | 1 x DisplayPort |
LAN Chipset | Realtek |
LAN Speed (Mbps) | Gigabit |
Bios Type | 128 Mb Flash ROM |
Bios Model | UEFI AMI BIOS |
Others | Software Features ASUS Exclusive Software Armoury Crate AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 2+ - EZ update AI Charger ASUS CPU-Z DAEMON Tools Norton Anti-virus software(Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Special Features ASUS 5X PROTECTION III - ASUS DIGI+ VRM - ASUS LANGuard - ASUS Overvoltage Protection - ASUS Safeslot - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM ASUS Sync - Standard RGB header(s) Accessories User´s manual I/O Shield 2 x SATA 6Gb/s cable(s) 1 x M.2 Screw Package 1 x Supporting DVD |
Manufacturing Warranty | 03 Years |
