Basic Information
| Supported CPU | Supports Intel 10th Gen Core i9, i7, i5, i3 & Pentium Processors Supports Intel 11th Gen Core i9, i7, i5, i3 & Pentium Processors Supports Intel Turbo Boost Technology 2.0 Supports Intel Turbo Boost Max Technology 3.0** ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Intel H410 |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Form Factor | mATX Form Factor 8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ) |
| Audio | Realtek ALC887 7.1-Channel High Definition Audio CODEC *2 - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - LED-illuminated design - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors |
CPU
| Chipset Brand | Intel |
| Chipset | H410 |
| Supported Sockets | LGA1200 |
Graphics
| Graphics | Integrated Graphics Processor * 1 x D-Sub 1 x HDMI 1.4b *Graphics specifications may vary between CPU types. |
Memory
| Type | DDR4 |
| Slots | 2 x DIMM |
| Supported Memory | DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory 10th Gen Intel Core i9/i7 CPUs support 2933/2800/2666/2400/2133 natively Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) OptiMem |
| Maximum Memory | Max. 64GB |
| Memory MHz | Up to 2933 |
Storage
| Storage Interface | 4 x SATA 6Gb/s port(s) |
| SSD Expansion Slot | 1 x SSD Expansion Slot |
Expansion Slots
| PCI | Intel 10th Gen Processors 1 x PCIe 3.0 x16 (x16 mode) Intel H410 Chipset 2 x PCIe 3.0 x1 |
| M.2 Socket | Total supports 1 x M.2 slots and 4 x SATA 6Gb/s ports Intel H410 Chipset : 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode) |
Connector & Ports
| HDMI | 1 x HDMI and 1 x D-Sub |
| USB (s) | Rear USB Port ( Total 4 ) 2 x USB 3.2 Gen 1 port(s)(2 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 6 ) 2 x USB 3.2 Gen 1 port(s) 4 x USB 2.0 port(s) |
| LAN Port (s) | Realtek® RTL8111H |
| Audio | 3 x Audio jack(s) |
| Internal I/O Ports | 1 x CPU Fan connector(s) 1 x Chassis Fan connector(s) 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode) 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x Speaker connector |
Network & Connectivity
| LAN Chipset | RTL8111H |
Technical Info
| Form Factor | mATX Form Factor 8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ) |
| Bios Type | 128 Mb Flash ROM |
| Bios Model | UEFI AMI BIOS |
Additional Info
| Others | Software Features ASUS Exclusive Software Armoury Crate AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert - EZ update ASUS CPU-Z AI Charger DAEMON Tools Norton Anti-virus software (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Special Features ASUS 5X PROTECTION III - ASUS DIGI+ VRM - ASUS LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot Core - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design Accessories I/O Shield 2 x SATA 6Gb/s cable(s) 1 x M.2 Anchor 1 x Supporting DVD User manual |
Warranty Information
| Manufacturing Warranty | 03 Years |
